写真
仕様
■Capacities:
960GB, 1.92TB, 3.84TB
■Performance1,2
-Seq. R/W 128K QD256: Up to 6500/3500 MB/s3
-4K QD1 Random Latency (typ.) R/W: 65/16 μs
4K QD1 Sequential Latency (typ.) R/W: 10/13 μs
-Random 4KB4 (QD32 x 8 workers) R/W: Up to
875K/100K IOPS
■Media
-128-Layer TLC5
■Supported Operating Systems
Windows Server 2022, Windows Server 2019,
Windows Server 2016
RHEL 7.8, 7.9 & 8..3
SLES 15
Driver Certifications
-Intel Developed Windows NVMe SSD Driver
Intel Developed ESXi VMD Driver
VMware IOVP- ESXi 7.0
VMware vSAN- ESXi 7.0
-Windows Hardware Compatibility Program
(Inbox Driver) – Server 2022, Server 2019, Server
201 6
UEFI 2.7
■Hardware-based AES-256 XTS Mode Encryption
■Compliance
NVM Express 1.3c
NVM Express Management Interface 1.0a
PCI Express Base Specification Rev 4.0
SFF-8639 Module Specification Rev 3.0, Ver
1.056
PCI Express Card Electro-Mechanical Spec. Rev
3.0
■Certifications and Declarations
-UL, CE, C-Tick, BSMI, KCC, Microsoft WHCP, VCCI
■Power
-12V Supply Rail & Optional 3..3V aux Supply Rail
for SMBus access over I2C
– Consumption: Up to 15W
Enhanced power-loss data protection
■
Endurance Rating7
– Up to 6.5PBW
■Reliability
-Uncorrectable Bit Error Rate (UBER): 1 sector per
1017 bits read
-Mean Time Between Failure (MTBF): 2 million
hours
– Host Sector Size: 512, 4096 Bytes，
■Temperature Specification
– Operating Temperature: 0° C to 70° C (SMART)
with specified airflow
Non-Operating Temperature8: -55° C to 95° C
一Temperature monitoring (In-band and out of
band)
-SSD Enclosure Touch Temperature can be
extended up to 80°C
-Thermal Throttling at 70° C (SMART)
-Thermal Shutdown at 80°C (SMART)
■Form Factor
– U.2 15mm
■Approximate Drive Weight:
960GB, 1.92TB: 148g +/- 10g .
-3.84TB: 157g +/- 10g
■Shock
-Operating: 1000G (0.5ms)
Non-operating: 1000G (0.5ms)
■1 Vibration
-Operating: 2.17 GRMS (5-700 Hz)
Non-Operating: 3.13 GRMS (5-800 Hz)
■Altitude .
Operating: -1,000 to 10,000ft.
– Non-Operating: -1,000 to 40,000ft.
■Product Ecological Compliance
-RoHS, REACH, EPEAT
Condition: New made in China
